B0813 Floating Series

Successfully passing the USCAR V3 vibration level test, the connector features a unique dual-independent spring arm design and a micro-stress floating structure, fully meeting the stringent requirements of applications such as three-electric systems and other demanding scenarios.

Viewing Series Products

Related parameters

Pitch

0.8 (mm)
Stacking Height (mm)

18/20/22/24 (mm)
Pin Count

40~120(pin)
Floating

Yes
Mount Type

SMT
Rated Current

0.5A
OperatingTemperature Range

-40℃ ~ 125℃
Floating Range

X/Y/Z : ±0.5mm
Rated Voltage

250V AC
Connection Method

Straight，Right Angle
Remark

Iriso 10128
